| 品牌 | 力图 |
|---|---|
| 型号 | LT-1390 |
Parameter
| Engraving area | 1300x900mm |
| Engraving speed | 0-64000mm/min |
| Laser power | 80W/120W/150W |
| Resolution ratio | 0.025mm |
| Minimum shaping character | 1mm |
| Resetting positioning accuracy | ±0.01mm |
| Power supply | AC220v±10%,50Hz |
| Gross power | <1250w |
| Operating temperature | 0°C-45°C |
| Operating humidity | 5%-95% |
| Graphic format supported | BMP,GIF,JPEG,PCX, TGA, TIFF, PLT, CDR, DWG, DXF |
| Net weight | 220KG |
| Dimension | 1500×1100×900mm |
|
|
|
Characteristic:
This serial models adopted DSP digital control technology integrated frame-structure to ensure the work stability.
The latest software can support Auto CAD, CorelDraw CAD, CAM and other graphical software, and make it available
to directly output pictures. The USB data interface can support heat play & plug .quick data transiting without taking
up computer resource. Chinese edition liquid display can make it easy for user to operate.
