品牌:净泰JINGTAI
外观尺寸:500支/包mm
类型:CCD擦拭棒系列
起订:5000支
供应:100000000支
发货:10天内
| 外观尺寸 | 500支/包mm |
|---|---|
| 类型 | CCD擦拭棒系列 |
| 适用场景 | 电子工业 |
| 采用材质 | 聚丙烯杆 |
| 产地 | 苏州市苏州市 |
| 尺寸 | 500支/包 |
| 款式 | 分体服 |
| 品牌 | 金泰 |
| 型号 | 海绵棉签条切割机 |
n 电子工业用无尘布头擦拭棒
(Clean cloth wipe stick - be - Electronic Industry)
产品特点
头部采用超细纤维无尘布或聚酯纤维无尘布,并经无尘清洗；
极低的发尘量；
长丝纤维擦拭头，无粘合剂，采用热封方式固定于PP杆上；
在10-100级无尘室真空包；
可用来擦拭各种试剂与溶液。
应用
可用IPA或丙酮等溶剂进行擦拭；
可应用润滑剂及其它液体.
Product properties
Swab top are made from clean cloth which includes micro- fiber and Polyester fiber;
The product almost has no dust out;
Swab top with Polyester fiber and without adhesive and it is fixed on PP pole by hot;
Vacuum packaging in C10-100 clean room;
Suitable to all kinds of reagent and solution.
Application
Wiping after dipping into IPA and acetone eagent;
Applied to lubricant and other liquid.
| Part NO. | head | Head Width | Head thickness | head length | Handle material | Handle width | Handle length | Total length | Packing （Thin or thick rod） |
| 2803A | Polyester Or Micro-fiber wipe | 12.7/13mm | 2.8/3.2mm | 25mm | polypropylene | 5.2mm | 102mm | 127mm | 100 swabs/bag |
| Part NO. | head | Head width | Head thickness | head length | Handle material | Handle width | Handle length | Total length | Packing （Thin or thick rod） |
| 2804A | Polyester Or Micro-fiber wipe | 14.2/14.5mm | 2.8/3.2mm | 25mm | polypropylene | 5.2mm | 102mm | 127mm | 100 swabs/bag |
| Part NO. | head | Head width | Head thickness | head length | Handle material | Handle width | Handle length | Total length | packing |
| 2805A | Polyester Or Micro-fiber wipe | 6.8mm | 2.0mm | 17.0mm | polypropylene | 3.2mm | 148mm | 165mm | 100 swabs/bag |
| 编号 | 头材质 | 头宽 | 头厚 | 头长 | 杆材质 | 杆宽 | 杆长 | 总长 | 包装 |
| 2803A | 聚酯或超细 | 12.7mm | 2.8 | 250mm | 聚丙烯 | 5.8mm | 102mm | 125mm | 100支/包 |
| 编号 | 头材质 | 头宽 | 头厚 | 头长 | 杆材质 | 杆宽 | 杆长 | 总长 | 包装 |
| 2804A | 聚酯或超细 | 13mm | 3.2mm | 25mm | 聚丙烯 | 5.8mm | 102mm | 125mm | 100支/包 |
| 编号 | 头材质 | 头宽 | 头厚 | 头长 | 杆材质 | 杆宽 | 杆长 | 总长 | 包装 |
| 2805A | 聚酯或超细 | 6.8mm | 2mm | 17mm | 聚丙烯 | 3.2mm | 148mm | 165mm | 100支/包 |
